VISAR 02 AR Polyester Film
VISAR 02 AR film is a convenient method of reducing the reflectance of flat surfaces.
It consists of a hard coated 100 micron thick polyester film over coated with an antistatic layer on top of which is the antireflective coating. The AR surface has a removable film which gives protection during the application process. There is an acrylic PSA (pressure sensitive adhesive) on the rear of the product with its own release liner.
VISAR 02 AR Film is available both in roll form (up to 1.25 meters wide), or in cut to size sheets.
Properties
|
Product Name |
VISAR 02 AR Film |
|
|
Substrate |
Polyester Film, 100 micron |
|
|
|
||
|
Property |
Value |
Test Method |
|
|
|
|
|
Minimum Reflectance |
0.8% (at 590nm) |
UV-VIS-NIR Spectrophotometer, Absolute reflectance (5 degree incidence) |
|
Luminous Reflectance |
1.20% |
UV-VIS-NIR Spectrophotometer, Absolute reflectance (5 degree incidence) |
|
Reflective Colour x y |
0.198 0.150 |
UV-VIS-NIR Spectrophotometer, Absolute reflectance (5 degree incidence) |
|
Total Luminous Transmittance |
93.6% |
Applied to float glass (1mm thick). Spectrophotometer |
|
Haze |
0.3 |
Applied to float glass (1mm thick). Haze meter |
|
Surface Resistivity |
3 GΩ/sq |
Surface resistivity meter
|
|
Coating Adhesion |
Good |
Cross hatch Tape Test
|
|
Pencil Hardness |
3 H |
1 Kg, JIS-K5400
|
|
Abrasion Resistance by Steel Wool |
Over 10 times both ways |
Steel wool (#0000) 200g/cm sq load
|
|
PSA Peel Test |
8.0 N/25mm
|
180ē peel method (JIS Z 0237) |
Figure Reflectance verses Wavelength
Durability
|
Property |
Value |
Test Conditions |
|
|
|
|
|
Thermal Ageing |
No Change |
80ēC, 1000 hours |
|
Heat-Humidity Test |
No Change |
60ēC, 90% RH, 1000 hours |
|
Heat- Cycle Test |
No Change |
-30ēC - 60ēC, 50 cycles |
Surface Tension
|
Test Media |
Contact Angle |
|
|
|
|
Water (distilled) |
100ē |
|
Oleic acid |
58ē |
Chemical Resistance
|
Chemicals |
Result |
Test Method |
|
|
|
|
|
NaOH 3% aq. solution |
Unchanged |
30 minute exposure under ambient conditions |
|
Na4OH 3% aq. solution |
Unchanged |
|
|
HCI 3% aq. solution |
Unchanged |
|
|
Kitchen cleaner 5% aq.solution |
Unchanged |
|
|
Glass cleaner |
Unchanged |
|
|
Isotonic NaCl solution |
Unchanged |
|
|
Silicone oil |
Unchanged |
|
|
Coca-Cola |
Unchanged |
|
|
Acetone |
Unchanged |
|
|
Ethanol |
Unchanged |
|
|
MEK |
Unchanged |
|
