Glass for Electronic & Industrial Applications
FTO Glass - Fluorine Tin Oxide coated Glass Pieces
Visiontek Systems offers a whole range FTO coated glass plus laser
scribed patterned FTO coated glass. Applications include solar and photovoltaics applications:
e.g. dye-sensitized cells, organic solar cells. FTO stands for fluorine
doped tin oxide (F:SnO2)
Prices are available on standard size sheets, or cut to size custom pieces. We can also supply patterned FTO glass pieces with a maximum sheet size of 450 x 300mm and with the thinnest line definition of 0.12mm. Please enquiry with details for an up to date quotation
Patterned FTO coated glass can also be supplied using a laser scribe patterning process
|
Product |
Thickness (mm) |
Visible Transmission (%) |
Haze | Roughness | FTO Sheet Resistance (Ohms/sq) |
|
|
|
|
|||
| TEC 7 | 2.2mm & 3.2mm | > 82% | 5% | 7 ohms/sq | |
| TEC 8 | 2.2mm | > 82% | 10% | 34.nm | 6 to 9 ohms/sq |
| TEC 9L | 4mm | >82% | <6% | 8 to 11 ohms/sq | |
| TEC 10 | 2.2mm & 3.2mm | > 80% | 9 to 15% | 9 ohms/sq | |
| TEC 11L x (iron free) | 3.2mm | > 81% | 11 to 15% | 10 to 16 ohms/sq | |
| TEC 15 | 2.2mm & 3.0mm | > 84% | <0.6% | 12.5nm | 12 to 15 ohms/sq |
| TEC T10 | 1.0mm | > 80% | <9% | 20nm | 8 to 10 ohms/sq |
| TEC T15 | 1.0mm | > 84% | <9% | 14 to 16 ohms/sq |
Note: L stands for Low iron. T stands for Thin. TEC‐9L and TEC‐11L are
references equivalent
to A9X and ST200 from Nippon Sheet Glass
FTO is more resistent to corrosion and high temperature treatments (up to
500‐550ºC). It
presents less plannar surface ( roughness ~50‐100 nm). It is used in a‐Si,
a‐Si/μ‐Si, CdTe,
perovskite and DSSC solar technologies
Please note that larger size sheets, up to 1200 x 600mm are available on requested with a minimum order value of 5 sheets
Also available ITO coated Glass , OLED Grade ITO Polished Glass, ITO coated Borosilicate Glass, ITO coated PEN Film and ITO coated PET Film
